350F 2.7V Super Capacitor
Feature & Benefits
● Operate temperature: -40℃~+70℃● Cycle life 1,000,000 duty times.
● Up to 30 years DC life
● Large power density
● Energy storage
● Advanced shock and vibration performance
● Threaded and weldable axial terminals
Application
● Pitching control system of Wind Turbine Generator● EV/HEV
● Solar energy conversion system
● Hybrid drive trains
● Mass transportation braking energy recovery system
● UPS/DVC
● Heavy duty machinery
● Locomotive engine startup system
Documents download
No.
Part Number
GTSP-2R7-357UN4
1
Rated Voltage
2.7V/DC
2
Surge Voltage
2.85V/DC
3
Capacitance
350F
4
Capacitance Tolerance
-10% to +20%
5
ESR/AC @1KHz
<2.8mΩ
6
ESR/DC
<3.2mΩ
7
Max. Working Current
24A
8
Max. Peak Current 1s
195A
9
Max. Leakage current 25℃,After 72 hours
0.85mA
10
Voltage Holding 25℃,After 72 hours
≥80%
11
Operating Temperature
-40℃~+70℃
12
Storage Temperature
-20℃~+50℃
13
Power Density
3125W/kg
14
Energy Storage
0.36Wh
15
Weight
70g
16
Cycle Life (25℃)
500,000 times
Constant current charging to UR,
constant current discharging to 1/2UR
△C/C≤30%; ESR≤2*ESR25℃
17
Load Life(65+2℃)
1500 hours
Under the rated voltage at 65 + 2 ℃ under the condition of storage of 1500 +48 / - 0 h, satisfy the standard of capacity and ESR, and no visible damage at the same time, no electrolyte leakage.
△C/C≤30% ; ESR≤2*ESR25℃
18
Temperature Characteristics
-40℃ △C/C≤30%; ESR≤2*ESR25℃
+65℃ △C/C≤30%; ESR≤2*ESR25℃
