10F 3.8V Li-ion Hybrid Super Capacitors

Radial type small size cell super capacitor with small size, big capacitance, Low LC and Low ESR
  • Brand:

    GTCAP
  • Item No.:

    GTSPL-3R8-106MR
  • shipping port:

    Shanghai
  • Model:

    GTSPL-3R8-106MR
  • value:

    10F
  • votage:

    3.8V
  • Feature:

    Small size,big capacitance,Low LC,Low ESR
  • grade:

    A
  • quality guarantee:

    1 years
  • production cycle:

    30 days
  • Applications:

    Solar LED light,Carcorder,Smart meters
  • MOQ:

    100pcs
  • Payment:

    T/T,L/C, Western Union,Paypal,Alipay
  • Color:

    Blue
  • Lead Time:

    20days
  • product origin:

    China
Products description

10F 3.8V Hybrid Super Capacitors


No.

产品型号

Part Number

GTSPL-3R8-106MR

1

额定电压

Rated Voltage

3.8V

2

最低工作电压

Min. Operating Voltage

2.5V

3

浪涌电压

Surge Voltage

4.2V

4

标称容量

Rated Capacitance

10F

5

容量允许公差

Capacitance Tolerance

±20%

6

最大交流内阻

Max. ESR/AC @1KHz

400mΩ

7

最大直流内阻

Max. ESR/DC

800mΩ

8

 额定充电电流

Rated Charge-discharge Current

0.075A

9

最大充电电流

Max.Charge-discharge Current<5s

0.5A

10

自放电电流3个月

Self-discharge 3 months

0.65μA

11

最大漏电流

Max. Leakage Current 72hrs

2 μA

12

工作温度

Operating Temperature

-15~+70/85(3.5V)

13

存储温度

Storage Temperature

-25~+85

14

循环寿命

Cycle Life

>500,000 times

15

重量

Weight

1.5g




Leave a message
If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
